The MEANWELL HLG-320H-24 is an IP67 LED switching power supply with 320 W output power, 24 V DC output voltage and 13.34 A output current. It provides constant-voltage and constant-current operation for LED lighting installations with high power requirements, and features a full-range AC input for 100–240 V AC, 50/60 Hz.
- IP67-rated and suitable for outdoor use
- Built-in active PFC filter
- Low-noise operation according to EMC standard EN 61000-3-2, class C
- Overload protection with shutdown and automatic recovery
- Protection against overheating, overvoltage, overload and short circuit
- Passive convection cooling
- Rugged aluminium housing in silver
- Fixed supply cord with open wires; output connection via cable only, without a connector
Technical specifications
- Input: 100–240 V AC, 50/60 Hz
- Output: 24 V DC, 13.34 A, 320 W
- IP classification: IP67
- Protection class: I
- Cable construction: 3 × 1 mm² H05RN-F; 2 × 2.08 mm² power cable
- Cable length: approx. 0.3 m
- Dimensions: 24.42 × 6.8 × 3.88 cm (L × W × H)
- Weight: 1.80 kg
Included
