StudioLive® AR16 USB 18-channel hybrid mixers make it simple to mix and record live shows, studio productions, band rehearsals, podcasts, and much more. This is a musician’s mixer: lightweight, versatile, feature-rich, and packed with analog connections and digital tools, yet easy to learn and use. Mix with PreSonus’® famous Class A preamps and three-band EQ. Create multitrack recordings and fly in backing tracks with a 24-bit, 96 kHz, USB 2.0 digital audio interface. Record and playback in stereo with the integrated SD™ digital recorder. Stream program music wirelessly, using onboard Bluetooth® connectivity. Compact and road-ready, StudioLive AR mixers provide a superior all-in-one solution for mixing and recording your performances.
FeaturesChannels and Buses
- 18-channel mixer
- 8 mono and 4 stereo channels, each with:
- 60 mm level fader
- Pan
- Mute
- PFL solo
- 1 stereo Super Channel (Ch. 17/18)
- 2 monitor buses with PFL solo
- 1 stereo effects bus
- 1 stereo effects return with:
- 60 mm master fader
- Dedicated monitor sends
- Effects bypass footswitch jack
Inputs and Outputs
- 2 instrument inputs
- 16 balanced line inputs
- 2 unbalanced inserts
- 12 balanced mic inputs with:
- Class A microphone preamp
- Global 48V phantom power
- Stereo Super Channel with:
- Stereo RCA inputs
- 1/8-inch stereo input
- Switchable SD™/USB stereo playback
- Bluetooth 4.1 input
- L/R XLR main outputs
- 2 balanced TRS monitor outputs
- 1 balanced TRS effects output
- L/R Control Room outputs with level control
- Headphone output with level control
Signal Processing
- Highpass filter on every channel
- Mono channels: 3-band semi-parametric EQ with sweepable mid-band
- Stereo channels: 3-band semi-parametric EQ
- Stereo effects processor with 16 presets
Recording Options
- 18x4 24-bit/96 kHz, USB 2.0 audio recording interface
- Record every channel plus the Main Mix
- 2x2 SD recorder
- Record main mix
- Supports SD™ and SDHC™ formats up to 32 GB
Integrated Software
- Capture™ recording software
- Studio One ® 3 Artist recording and production software (DAW)
Power
- Internal power supply
- Standard IEC power connector
Physical
- Sturdy metal construction
- 60 mm faders
- Rackmount kit included
