Features

• Two-way full range speaker with 15-inch LF driver and a 1.4-inch compression driver.
• Passive crossover board features separate cooling zones to ensure safe and continuous operations in the toughest environments.
• Wide dispersion of 90 × 60 degrees, with rotatable horn for horizontal installation.
• Designed for fixed and mobile applications, with a wide array of flying options.
• Features top hats for quick set-up.
• NL4 INPUT and LINK OUT connections as standard.
• Robust enclosure made from premium multi-laminate birch plywood.
• Impact resistant textured paint finish.

Specification of XY-152

Enclosure Type: Two-way passive, reflex-loaded

Frequency Response: 50 Hz to 20 kHz

Sensitivity (1 W/1 m): 98 dB

Nominal Impedance: 8 O

Power Handling: 650 W RMS, 1300 W Program

Maximum SPL: 126 dB cont., 132 dB peak

Dispersion: 90 °H × 60 °V, Rotatable

Driver Configuration: 15 inch (380 mm) neodymium LF cone driver,
1.4 inch (36 mm) exit neodymium HF compression driver

Crossover: Asymmetric internal passive crossover

Connectors: 2 × Neutrik SpeakON™ NL4

Dimensions (W×H×D): 440 mm × 715 mm × 444 mm (17.3 inch × 28.1 inch × 17.5 inch)

Weight: 29 kg (63.9 lbs)

Rigging and Hardware:

• 8 × M10 threaded mounting points (4 top/4 bottom),
• 3 × M10 threaded mounting points on rear,
• 4 × M10 threaded mounting points on side (2 left/2 right),
• 4 × M8 threaded points on rear (for wall mount bracket),
• 2 × flush handles (1 left/1 right),
• 1 × 35 mm polemount socket

Grille: Hex punched steel

Enclosure: 15 mm (0.6 inch) birch plywood

Finish: Impact-resistant, Black semi-matt textured

Suggested Power Amplifier: Recommended : K3DSP (Minimum : M30DHDSP)

Accessories: polemount socket cover (-W model only)
