Features

• Two-way full range speaker with 12-inch LF driver and a 1.4-inch compression driver.
• Passive crossover board features separate cooling zones to ensure safe and continuous operations in the toughest environments.
• Wide dispersion of 90 × 60 degrees, with rotatable horn for horizontal installation.
• Designed for fixed and mobile applications, with a wide array of flying options.
• Features top hats for quick set-up.
• NL4 INPUT and LINK OUT connections as standard.
• Robust enclosure made from premium multi-laminate birch plywood.
• Impact resistant textured paint finish.

Specification of XY-122

Enclosure Type: Two-way, passive, reflex-loaded

Frequency Response: 70 Hz to 20 kHz

Sensitivity (1 W/1 m): 101 dB

Nominal Impedance: 8 O

Power Handling: 400 W RMS, 800 W Program

Maximum SPL: 127 dB cont., 133 dB peak

Dispersion: 90 °H × 60 °V, rotatable

Driver Configuration: 12 inch (320 mm) neodymium LF cone driver,
1.4 inch (36 mm)exit neodymium HF compression driver

Crossover: Asymmetric internal passive crossover

Connectors: 2 × Neutrik SpeakON™ NL4

Dimensions (W×H×D): 380 × 622 × 360 mm (15 × 24.5 × 14.2-inch)

Weight: 23 kg (50.7 lbs)

Rigging and Hardware:

• 8 × M10 threaded mounting points (4 top/4 bottom),
• 2 × M10 threaded mounting points on rear,
• 4 × M10 threaded mounting points on side (2 left/2 right),
• 4 × M8 threaded points on rear (for wall mount bracket),
• 1 × flush handle on rear,
• 1 × 35 mm polemount socket

Grille: Hex punched steel

Enclosure: 15 mm (0.6-inch) birch plywood

Finish: Impact-resistant, Black semi-matt textured

Suggested Power Amplifier: Recommended : K3DSP (Minimum : M30DHDSP)

Accessories: polemount socket cover (-W model only)
